High Voltage Lithium Battery
Optimized & Industry-ready Solutions
High Voltage Lithium Battery
The Yibai energy high voltage lithium battery is a safe energy storage lithium battery system, with voltage optional from 192V to 480V, suited for residential or light commercial buildings that are powered by high voltage. The battery system is created at an automotive-grade craft, bringing a highly reliable power source to ensure the normal operation of the appliances.
This high voltage lifepo4 battery system is suitable for homes, businesses, industries, agriculture, utility-scale applications, transportation, and renewable energy systems, seamlessly integrating with the grid to ensure power supply for critical loads.
Product Features
Reliable performance
We use stable lithium iron phosphate technology, ensuring high round-trip efficiency, a wide operating temperature range, and good durability.
Communication protocal
It can communicate via RS485, RS232, and CAN interfaces, supporting customized communication protocols and control software.
Long Lifespan
The high voltage lithium battery has no memory effect, with a capacity retention rate of up to 96%, providing a cycle life of 6,000 times.
10-Year Warranty
The yibai energy high voltage lithium battery consumes less energy, has high transmission efficiency, and comes with a 10-year after-sales warranty, giving you peace of mind.
Smart BMS
The BMS guarantees safety and availability, with strong compatibility, supporting three-phase off-grid inverters and hybrid inverters.
Stackable design
The stackable modular design allows for flexible capacity expansion, making it easy for you to disassemble, transport, install, test, and maintain.
Compact structure
The yibai energy high voltage energy storage battery is compact in size, convenient for indoor and outdoor installation, and space-saving; it has wheels at the bottom for easy mobility.
Eco friendly
The materials used in the high voltage li ion battery contain no harmful substances, helping to reduce carbon emissions and having a positive impact on the environment.
Technical Parameters
| Model | HV19250 | HV192100 | HV24050 | HV240100 | HV38450 | HV384100 | HV48050 | HV480100 |
| Nominal Voltage | 192V | 240V | 384V | 480V | ||||
| Nominal Capacity | 50Ah | 100Ah | 50Ah | 100Ah | 50Ah | 100Ah | 50Ah | 100Ah |
| Energy | 9.6kWh | 19.2kWh | 12kWh | 24kWh | 19.2kWh | 38.4kWh | 24kWh | 48kWh |
| Charge Cut-off Voltage | 218V | 200V | 435V | 545V | ||||
| Discharge Cut-off Voltage | 160V | 270V | 320V | 400V | ||||
| Recommended Charge Current | 25A | 50A | 25A | 50A | 25A | 50A | 25A | 50A |
| Max. Charge Current | 50A | 100A | 50A | 100A | 50A | 100A | 50A | 100A |
| Max. Constant Discharge Current | 50A | 100A | 50A | 100A | 50A | 100A | 50A | 100A |
| Peak Current | 100A | 200A | 100A | 200A | 100A | 200A | 100A | 200A |
| Dimension | 460*330*480mm | 600*600*1600mm | 460*330*640mm | 1530*600*600mm | 460*330*780mm | 600*600*1600mm | 600*600*1600mm | 1200*600*1600mm |
| 18.1*13*18.9in | 23.6*23.6*63in | 18.1*13*25.2in | 60.2*23.6*23.6in | 18.1*13*30.7in | 23.6*23.6*63in | 23.6*23.6*63in | 47.2*23.6*63in | |
| Weight | 100kg/220.5lbs | 190kg/418.9lbs | 170kg/374.8lbs | 260kg/573.2lbs | 280kg/617.3lbs | 500kg/1102.3lbs | 350kg/771.6lbs | 600kg/1322.8lbs |
| Qty/20GP/40GP | 130pcs/190pcs | 24pcs/48pcs | 75pcs/110pcs | 24pcs/48pcs | 45pcs/65pcs | 24pcs/35pcs | 24pcs/48pcs | 12pcs/24pcs |
| Communication | RS485/CAN | |||||||
| Temperature | Charge Temperature: 0~ 60°C；Discharge;-15~ 60°C | |||||||
