48V 150Ah Rack mount lifepo4 battery
Optimierte und industrietaugliche Lösungen
48V 150Ah Server LiFePO4 Battery
- Compact rack-mounted design: Modular cabinet structure optimizes space efficiency for scalable installations.
- Seamless capacity expansion: Battery racks support series/parallel connections to meet growing energy demands.
- Smart BMS with RS485/CAN: Auto-balancing cell protection and dual communication protocols ensure stable operation.
- Mass parallel connectivity: Up to 16 units parallel connection for flexible capacity customization.
- CATL LiFePO4 cells: Premium Grade A cells ensure safety and consistent performance.
- 6,000+ deep-cycle durability: Robust lithium iron phosphate chemistry guarantees extended discharge cycles.
- Real-time LCD status monitoring: Front-panel display shows SOC, voltage, and system diagnostics instantly.
Produktmerkmale
Hoher Sicherheitsstandard
Yibai enery large scale energy storage lithium battery is a cutting-edge battery solution that boasts a range of features designed to deliver exceptional reliability. It employs LiFePO4 chemistry to guarantee high safety standards. The battery will deliver consistent performance over an extended period of time, making it an ideal choice for demanding applications.
Built-in Smart BMS with RS485/CAN
The intelligent BMS can maintain the self-balancing state of the battery and protect each series of cells.
Supports for parallel connection
The 48V 150Ah server LiFePO4 battery supports 16 batteries in parallel max, scalable capacity to better suit your needs.
Langes Leben
Die Lithiumbatterien von Yibai Energy haben eine bis zu 10-mal längere Lebensdauer als Blei-Säure-Batterien und bieten auch nach 3.000 Zyklen noch 80% der Nennkapazität.
Automotive grade manufacturing
In addition to its use of high-quality LFP chemistry, this battery also benefits from automotive-grade manufacturing processes. This guarantees that the battery is built to the highest standards of quality, with rigorous testing and quality control measures in place to ensure that every unit meets the exacting specifications. What’s more, we can customize the specifications, the logos on the LCD screen, the communication protocols, etc, allowing the battery to meet the specific needs of different industrial and commercial applications.
Wartungsfrei
Yibai lithium batteries are maintenance-free, with no watering, no corrosion. Low self-discharge lithium batteries lose only less than 3% per month when they’re idle for long time storage, while lead-acid is about 30%.
LCD Digital Display
All server rack lithium batteries are equipped with an LCD digital display on the casing, allowing users to understand the status of the battery in real-time.
Sorgenfreie Lagerung
Lithiumbatterien haben eine geringe Selbstentladung von weniger als 3% pro Monat, so dass auch bei gelegentlichem Gebrauch eine zuverlässige Leistung gewährleistet ist.
Technische Parameter
| Modell | YB-RACK48150 |
| Standard Voltage | 51.2V |
| Standard Capacity | 150Ah |
| Nennkapazität | 7.68kWh |
| Working Voltage | 43.2-57.6V |
| Standard Charging Current | 100A |
| Standard Discharging Current | 150A |
| Vorgeschlagenes DOD | 80% |
| Zyklus Leben | >6000 Zyklen |
| IP-Bewertung | IP20 |
| Discharge Operating Temperature | -20°C – 50°C |
| Charging Operating Temperature | 0°C-45°C |
| Maximum Parallel | 16PCS |
| Kommunikation | RS232/CAN/RS485 (WIFI/BT optional) |
| Anzeige | LCD display screen (touch screen optional) |
| Garantie | 5 Jahre |
| Zertifikat | UN38.3/MSDS/CE/ROHS/FCC |
| NW.(kg) | 76 |
| Größe des Produkts (mm) | 442*400*311 |
| Qty/20GP/40GP | 175pcs/250pcs |
